## How to Draw an Infinity of Products (with ellipses and cylinders)

Transcript below

Hey guys

Welcome to the “Sketching Mini-Tutos”!

Sketching from Chouchou from me, Chou-Tac.

So how to draw an infinity of products using ellipses and cylinders.

Alright,

we are going to draw some quick doodles right here

to see what we can draw.

So here are the basics:

one axis, two ellipses and you connect.

Then this is a PRINGLES box.

Do you know Pringles?

These chips that you can eat in the cylinder box.

You can find them in different sizes.

As you can see here we are going to draw a small logo here.

So it get more meanings for us.

This is basically the logo with the big mustache of Mr. Pringles!

My cylinder is a bit slanted for this doodle and we can we adjust it a bit.

If we want to.

But for these cases,

just to show you to communicate that

you can do different sizes of pringle box

and each of them has different usage.

You can get a small one for the more portable.

The middle one is for the basic

and the slim one which is more like let’s say diet packaging.

When you draw cylinders,

remember that

there is a difference between the top and below ellipse.

The one on the top is thinner and the one in the middle is bigger.

So the three steps: Axis, ellipses and connect.

This is the ultra-simple way to draw cylinders.

With these cylinders,

we can draw more things!

Like here is a cocktail glasses.

We did exactly the same things:

Axis, ellipses and then you connect.

It is just that some ellipses or bigger than others.

Here I’m drawing

the cherry inside with some alcohol inside.

And I want to “break” the stick

so it gives a sensation of reflection on the water.

Let’s say…

How do we call that?

There are diffractions in the lights?

Distortion of the light let’s say.

And yeah don’t forget the water or the thickness.

I can see that

my bottom ellipse is not as wide enough.

So this is magic with sketching

is don’t try to look for perfection when you doodle,

but feel the curves. right here.

Like I draw as you can see the middle ellipse

It is actually where it’s the widest area.

You have to feel you’re pulling the curve going out.

Okay?

It is really like a mental trick.

You do not only visualize on paper what you want.

You have to feel that tension.

You want to know that this wide area

is actually

where the curves are turning

on the left and all the rights

because this is the furthest distance

on the side of this glass.

Okay?

Now let’s draw the thickness here

which is thicker at the bottom

because it’s something which is more heavier.

Let’s add some ice cubes inside and a straw.

So the straw is also going to be broken

for the light distortion inside.

Let’s add a bit some hatching for the inside view

which is totally optional.

You can draw an infinity of kind

of glasses that you want.

Here is some Champagne.

Choose the length of the sticks and so on.

It’s total freedom.

Some bubbles.

Explore some forms and sizes.

Do not only draw the one I’m showing you here.

Go and explore as many as you want.

Always think of

Okay?

Is it for cocktails?

Is it for cognac?

Is it for water?

And so on…

Let’s see some common mistake

that we see from beginners.

It’s that you are drawing some pointy edges of the cylinders.

This is more like drawing what you see.

But we have to visualize

seeing through to avoid this flat version of the cylinder.

Okay?

Mistake number three is:

The Tower of Pisa.

Which is like a cylinder that is just slanted in that way.

So how to solve it?

which is also called the MINOR AXIS.

Then you connect them .

So slim ellipse on the top,

thicker below.

Here is a simple trick.

If the paper is in front of you like,

this is going to be difficult

if it’s parallel to your body.

But what you have to do

is to slant your paper to 45 degree

aThen you will get a natural position of sketching.

Okay?

This is going to make the whole difference.

Alright.

It is like that.

You got the 45-degree and very natural.

and if it is vertical like this,

you will maybe draw a potato shape.

Okay?

Remember that the ellipse also plays with symmetry.

Alright.

In the cylinder,

you have to think of

a lot of series of disks piling it on top of them.

Let’s recapitulate

You have a fast method here to draw the cylinders

which is easy to modify

and create as many shapes as you want.

Always think of the story that will give you the shape.

Always see in three dimensions

so you can see through your forms.

So you won’t get flat but in 3d volumes.

Always think of STRATEGY when you’re drawing

and if you want to go further

like on this tutorial

you need to draw

with multiple angles by drawing inside the box.

The cylinder inside the box is like this.

Just give you a very quick preview here.

and here we go.

all right so see you in the next videos!

Bye-Bye!

the Beginner guide as well in the blog.

You have the link inside the description.

So you can make your first steps in design sketching

getting the right habits from the pros.

All right.

See you.

Bye-bye.
